Physics research laboratory at PEC University of Technology, Chandigarh is equipped with various instruments of synthesis of materials and characterization. The department of physical sciences is engaged in current experimental physics of interest i.e. Multiferroics, Nanomaterials and Piezoceramics materials. Physics research laboratory also involves in conducting B.E, M.E and doctoral research programs. Laboratory equipment refers to the various tools and equipment used by B.E/M.E students and research scholars working in a laboratory. These include tools such as muffle furnace, spin coater, water distillation plant, hydraulic press, magnetic stirrer, PE loop tracer and LCR meter etc. The equipments are shown below:
Equipments
![Dc Polling Unit Image dc-polling-unit](/sites/default/files/images/dc_polling_unit.jpg)
DC Poling Unit
It is a device used to pole the dielectric samples with a maximum limit of 4kV/mm.
![Poop Tracer Lab pe-loop-tracer](/sites/default/files/images/pe_loop_tracer.jpg)
PE Loop Tracer
Device used to determine the ferroelectric properties of insulating materials.
![Weighing Balance Lab weighing-balance](/sites/default/files/images/weighing_balance.jpg)
Weighing Balance
It is used to measure the weight of chemicals with a precision of 0.1mg
![Box Furnace Lab box-furnace](/sites/default/files/images/box_furnace.jpg)
Box Furnace
Programmable furnace with the maximum operating temperature of 1350 oC
![Double Stage Plant double-stage-distillation-plant](/sites/default/files/images/double_stage_distillation_plant.jpg)
Double Stage Distillation Plant
This is used to purify the water.
![Magnetic Stirrer Image magnetic-stirrer](/sites/default/files/images/magnetic_stirrer.jpg)
Magnetic Stirrer
The employs a rotating magnetic field to cause a stir bar immersed in a liquid to spin very quickly, thus stirring it
![Ball Mill Lab ball-mill](/sites/default/files/images/ball_mill.jpg)
Ball Mill
It is a type of grinder used to grind and blend materials.
![Hydraullic Lab hydraullic-press](/sites/default/files/images/hydraullic_press.jpg)
Hydraulic Press
It is used to make the pellets with the die punch. The maximum pressure that can be applied is 30 tons.
![Spin Coater Image spin-coater](/sites/default/files/images/spin_coater.jpg)
Programmable spin coater
Spin coating is a procedure used to deposit uniform thin films to flat substrates. Usually a small amount of coating material is applied on the center of the substrate, which is either spinning at low speed or not spinning at all. The substrate is then rotated at high speed in order to spread the coating material by centrifugal force.
